SmartWise Mini BT (WiFi + Bluetooth) eWeLink app compatible smart relay (16A), for wired and wireless wall switches

This new eWeLink app compatible relay switch from SmartWise provides similar features as Sonoff Mini R2: eWeLink app based remote control, scheduled on/off, inching, and switch from wired wall switch.

But it has an increased 16A max. output, and it also has an embedded eWeLink-Remote (Bluetooth) receiver, and can switched from compatible Bluetooth wireless wall switches and Bluetooth remote controllers.


All product prices include VAT.
Note: Guest users see prices with estimated VAT amount. The payable price with your local value-added tax amount will be calculated based on your shipping address, added at checkout or set in your user profile.

Brand:
SmartWise
Supported protocols:
eWeLink-Remote (direct), Wi-Fi
in stock (30+ pcs)
9.38
Details

SmartWise Mini BT is a brand new 2023 product with similar basic capabilities as Sonoff Mini R2 relay:

  • as it connects to eWeLink cloud platform via Wi-Fi,
  • as it is also eWeLink app compatible, can be remotely turned on/off from app,
  • as it supports scheduled on/off, timer, loop control,
  • as it supports auto-on and auto-off (inching)

AND as an extra feature, it also has an embedded eWeLink-Remote / Bluetooth receiver, which supports pairing with up to 32 pcs of compatible wireless Bluetooth switches and Bluetooth remote controllers.


Thanks to its small size, it can built in behind a power socket or light switch in the wall box, and it can be also connected to the (traditional) physical edge switch, so it can be both controlled by the physical switch and mobile app via the internet. (Push button / momentary switches are not supported.)

Moreover, it can be switched froma several types of Bluetooth wireless switches and Bluetooth remote controllers, too.


It is perfect solution to smart control traditional sockets via app and also a remote controller (or wireless Bluetooth wall switch), or make a traditional wall smarter and wirelessly remote controllable from another wireless switch.

By using the smart relay switch you can remotely turn ON or OFF any of your appliances, and you can conveniently set a scheduled turn OFF to save energy and cost, or set a LOOP control.


Product features:

  • Small compact size - it fits behind power sockets and wall switches into the wall box
  • Works with traditional physical switch - when installed behind traditional switches, it support both physical switch and WiFi remote switch (has dry contact switch input)
  • Has embedded Bluetooth receiver - supports up to 32 pcs of wireless Bluetooth wall swicthes and remote controllers
  • Remote ON / OFF – Anytime, anywhere, from now on you can turn all your appliances on and off remotely
  • eWeLink mobile App support – Free iOS and Android mobil App: eWeLink
  • Sync status – Check actual relay status (turned ON or OFF) with the mobile App
  • Timer – Various timer functions: single time, scheduled turn on/off, countdown/timer, loop.
  • Auto-off and Auto-on, supports inching settings
  • Share control – Control the device together with your family
  • Group control – You may create groups of similar devices in eWeLink app to turn them ON / OFF together with one tap in the app
  • Smart scene – Triggered ON/OFF by temperature, humidity, motion or other sensors, or switch triggered by another smart device
  • Compatibility – Works perfectly with Amazon Alexa, Google Assistant, IFTTT and Google Nest


Info
Product type:
smart eWeLink relay module, with Bluetooth (eWeLink-Remote) receiver
Colour:
white
Device power supply:
100V-240V AC
DIN rail compatible:
no
Embedded relay:
yes
Dimmer feature:
no
Power consumption metering:
no
Number of gangs / circuits:
1
Dry contact (voltage free) switching:
no
NO/NC switch:
no
Number of phases:
1
Physical on/off button on device:
yes, on the back side
External switch supported:
yes
2-way or 3-way switching:
yes, works with wired two-way switches, and also supports SmartWise's wireless Bluetooth switches
Wi-Fi:
yes
Zigbee:
no
Thread:
no
Z-Wave:
no
Bluetooth:
yes, Bluetooth-based pairing, also Bluetooth-based remote control by SmartWise eWeLink-Remote devices
Controllable from internet:
yes
Manufacturer smartphone app:
yes, free app: eWeLink (Android, iOS)
Cloud mode:
yes, default mode is to connect to the eWeLink cloud
LAN mode:
yes, if the connection with the eWeLink cloud is disconnected, limited features
MQTT support:
no
Notification functions:
eWeLink app notification on smartphone
History:
yes: on/off history in the app
Warranty:
24 Month
Warranty type:
Warranty
Size:
40 x 40 x 20 mm
Weight:
35 g/pcs
